KF142V - 5.08mm

[cescbp]

---

Name of the part❗

Your previous work, similar parts
[(https://forum.fritzing.org/t/part-requests-kf235-and-kf142r/19420)]

Top view❗

Datasheet❗
The official documentation of the part manufacture is linked here:

https://es.aliexpress.com/item/1005009248924968.html?spm=a2g0o.order_list.order_list_main.5.4a33194duPXppO&gatewayAdapt=glo2esp#nav-description

Type

[x ] Jack, fixed part of a connector pair, header (J)

[vanepp]

A google search of the form “ fritzing part kf142v-5.08mm” (which is the best way to find available parts) turns up this post

Clamp Terminal Bloc KF142R 5.08 2P

Hello here is a KF142R clamp terminal block in 2 pin KF142R-5.08-2P.fzpz (6.7 KB) [KF142R-2PIN]

which may or may not do what you want. Otherwise you would need to specify the number of pins you want.

Peter

[cescbp]

@vanepp

A google search of the form “ fritzing part kf142v-5.08mm” (which is the best way to find available parts) turns up this post

Hello here is a KF142R clamp terminal block in 2 pin KF142R-5.08-2P.fzpz (6.7 KB) [KF142R-2PIN]

which may or may not do what you want. Otherwise you would need to specify the number of pins you want.

Peter

Right, sorry about that. There are two versions — horizontal and vertical connection. I want the vertical one, the 4-pin model.

[vanepp]

This part should do what you want. Before ordering boards print the pcb footprint out at 1:1 scale (the default) and compare it to a real part.

kf142V_5_08mm-4p.fzpz (3.7 KB)

Peter
