Radial Leaded Fuse - PFRA.030

Name of the part
Fuse PFRA.030

Previous work, similar parts
N/A

Top view
This picture shows the part from above, so that is easy to see were connectors should go, and which diameter they have.

Captura de pantalla 2025-01-14 a las 20.13.23

Captura de pantalla 2025-01-14 a las 20.16.52

Datasheet
The official documentation of the part manufacture is linked here:

PFRA.030

Symbology…

Captura de pantalla 2025-01-14 a las 20.15.31

Type
I did not read this
Breakout board, sub assembly, plug in module (A)
Antenna (AE)
Battery (BT)
Capacitor (C)
Diode (D)
Display (DS)
Fuse (F)
Hardware , mounting screws, etc. (H)
Jack, fixed part of a connector pair, header (J)
Relay (K)
Inductor, Coil, Ferrite bead (L)
Loudspeaker, Buzzer (LS)
Motor (M)
Microphone (MK)
Plug, moveable part of a connector pair (P)
Transistor (Q)
Resistor (R)
Thermistor (RT)
Varistor (RV)
Switch (S)
Transformer (T)
Integrated Circuit (IC)
Crystal, Oscillator (Y)
Zender diode (Z)
Other (please specifiy)

Footprint
THT

A google search of the form “fritzing part radial leaded fuse” turns up several hits one of which will likely do you.

Peter

Unfortunately, on this occasion I have not centered any option that works, this fuse is very small and the distance between holes is between 4’4 to 5’8mm…

Actually other than the pcb hole size the little fuse part works fine. To correct the hole size to 1.3mm as specified this part should do what you want.

PFRA_030.fzpz (5.8 KB)

Peter

1 Like

Thankss!!! Now yes!! :heart_eyes:
