Looking for H766 T-Halow

parts help
1

I need help to get fritzing part H766 T-HALOW from Liligo. Anyone have any source to this part?

Thank you very much.

image1920×1920 287 KB

2

image1000×1000 120 KB

image1000×1000 90.1 KB

image903×398 89.7 KB

3

The images available are not clear enough to make a part for this. I can’t read the labels on the pins with enough accuracy (and am out of time as well unfortunately.) Sorry about that.

Peter

4

You got lucky! I got a bit of time and found a better image of the board so this part should do what you want. Note the mounting holes in pcb are not drilled by default. If you want the mounting holes to be drilled you need to drag the core part→pcb → hole part in to your sketch, place it over the hole in silkscreen and set the hole size in Inspector appropriately.

LilyGo-H766-T-HALOW.fzpz (60.5 KB)

Peter

5

Thank you Peter! You’re trully the best!
