I am looking for a part for the RV3028

parts help
1

Name of the part
RV3028

Previous work, similar parts
I could not find any equivalent via Google or forum

Top view
This picture shows the part from above, so that is easy to see were connectors should go, and which diameter they have.

image image

Datasheet
The official documentation of the part manufacture is linked here:

RV3028 datasheet

Type
I did not read this
Breakout board, sub assembly, plug in module (A)
Antenna (AE)
Battery (BT)
Capacitor (C)
Diode (D)
Display (DS)
Fuse (F)
Hardware , mounting screws, etc. (H)
Jack, fixed part of a connector pair, header (J)
Relay (K)
Inductor, Coil, Ferrite bead (L)
Loudspeaker, Buzzer (LS)
Motor (M)
Microphone (MK)
Plug, moveable part of a connector pair (P)
Transistor (Q)
Resistor (R)
Thermistor (RT)
Varistor (RV)
Switch (S)
Transformer (T)
Integrated Circuit (IC)
Crystal, Oscillator (Y)
Zender diode (Z)
Other (please specifiy)

Footprint
3.2mm ceramic casing

2

This part should do what you want. Note before ordering boards print the pcb output out at 1:1 scale (the default) and compare it to a real part as I don’t have one.

RV3028.fzpz (4.6 KB)

Peter

1 Like
3

Thank you very much, Peter, you are amazing.

4

Hi Peter,

I have used your part and altered it to suit the RV3032.

RV3032.fzpz (7.6 KB)

It should be straight forward as most changes were just alterations in the parts editor (1.0.5) but if you want to have a look this would be appreciated.


5

Looks like it should be fine. I ran it through FritzingCheckPart.py which had no errors and it appears to load fine.

Peter

1 Like
6

I have “prettyfied” both the RV3028 as well as the RV3032 by adding an individual icon as well as modifying the family.

RV3028_2.fzpz (7.9 KB)

RV3032_2.fzpz (8.0 KB)
