ESP32-S3 Dev Board 44 Pin (ESP32-S3-WROOM-1-N16R8, Dual USB-C) Fritzing part

[DIYables]

Hello,

We would like to share the Fritzing part for DIYables ESP32-S3 Dev Board 44 Pin (ESP32-S3-WROOM-1-N16R8, Dual USB-C).

You can download it here: DIYables ESP32-S3 Dev Board 44 Pin (ESP32-S3-WROOM-1-N16R8, Dual USB-C) Fritzing Part — Import into Fritzing to draw wiring diagrams and breadboard layouts with this board

Or download from the product pages:

• ESP32-S3 Development Board ESP32-S3-WROOM-1-N16R8 Dual USB Type-C, Presoldered
• ESP32-S3-WROOM-1-N16R8 Dev Board and 44 Pin Screw Terminal Expansion Board Combo
• ESP32-S3-WROOM-1-N16R8 Dev Board and Solder-Free GPIO Expansion Board Combo
• ESP32 S3 Starter Kit 23 in 1 with ESP32-S3-N16R8 Dev Board
